REAR WHEEL
Parts (31)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2101000104430A Rear wheel cpl. 5x17" black | Rear wheel cpl. 5x17" black | 1 | — | Check availability | |
| 2 | 58709076000 VALVE CPL. BREMBO DUKE 2003 | VALVE CPL. BREMBO DUKE 2003 | 1 | — | Check availability | |
| 3 | 75310011000 BEARING SPACER TUBE L=106MM 07 | BEARING SPACER TUBE L=106MM 07 | 1 | — | Check availability | |
| 4 | 0625062052 Grooved ball bear. 6205-2RSHC3 | Grooved ball bear. 6205-2RSHC3 | 2 | — | Check availability | |
| 5 | 0472052200 CIRCLIP DIN0472-52X2 | CIRCLIP DIN0472-52X2 | 1 | — | Check availability | |
| 6 | 0760305271 Radial shaft seal 30X52X7 | Radial shaft seal 30X52X7 | 1 | — | Check availability | |
| 7 | 60110013000 SPACER BUSH. REAR WHEEL R/S 06 | SPACER BUSH. REAR WHEEL R/S 06 | 1 | — | Check availability | |
| 8 | 60010015000 Spacer ring 03 | Spacer ring 03 | 1 | — | Check availability | |
| 9 | 75010051040 SPROCKET STEALTH 40T 07 | SPROCKET STEALTH 40T 07 | 1 | — | Check availability | |
| 10 | 0019080206S FLAT HEAD SCREW M. ISA45 M8X20 | FLAT HEAD SCREW M. ISA45 M8X20 | 6 | — | Check availability | |
| 11 | 76010057000 HEX NUT M8 WS17 | HEX NUT M8 WS17 | 6 | — | Check availability | |
| 12 | 76010020000 NILOS RING 6206AV | NILOS RING 6206AV | 1 | — | Check availability | |
| 13 | 76010012000 OUTER DISTANCE BUSHING | OUTER DISTANCE BUSHING | 1 | — | Check availability | |
| 14 | 0625062060 BALL BEARING 6206 TNH C3 | BALL BEARING 6206 TNH C3 | 1 | — | Check availability | View Details |
| 15 | 0472062200 Steering Insert Circlip | Steering Insert Circlip | 1 | — | Check availability | |
| 16 | 76010014000 INNER DISTANCE BUSHING | INNER DISTANCE BUSHING | 1 | — | Check availability | |
| 17 | 76010059100 DAMPING RUBBER | DAMPING RUBBER | 5 | — | Check availability | |
| 18 | 76010060000 BRAKE DISC REAR 240MM | BRAKE DISC REAR 240MM | 1 | — | Check availability | |
| 19 | 76009062000 Special screw M8X25 SL TX40 | Special screw M8X25 SL TX40 | 5 | — | Check availability | |
| 20 | 76042021000 Sensor wheel rear | Sensor wheel rear | 1 | — | Check availability | |
| 21 | 60010081144 WHEEL SPINDLE REAR CPL. | WHEEL SPINDLE REAR CPL. | 1 | — | Check availability | |
| 22 | 60010084000 Chain tension adjuster, right, | Chain tension adjuster, right, | 1 | — | Check availability | |
| 23 | 60010086000 COLLAR NUT WH. SPINDLE REAR 03 | COLLAR NUT WH. SPINDLE REAR 03 | 1 | — | Check availability | |
| 24 | 58414030000 HH COLLAR NUT M10X1,25 WS=13 | HH COLLAR NUT M10X1,25 WS=13 | 2 | — | Check availability | |
| 25 | 50304040100 screw M10x1.25x50 WS10 | screw M10x1.25x50 WS10 | 2 | — | Check availability | |
| 26 | 76910065118 chain DID 118 roll | chain DID 118 roll | — | — | Check availability | |
| 27 | 76910066000 Rivet link chain DID 520 VP2-T | Rivet link chain DID 520 VP2-T | — | — | Check availability | |
| 98 | 00050002025 DRIVETRAIN KIT 690DUKE 16T/40T | DRIVETRAIN KIT 690DUKE 16T/40T | — | — | Check availability | View Details |
| 28 | 7601005004433 SPROCKET SUPPORT CPL. | SPROCKET SUPPORT CPL. | 1 | — | Check availability | |
| 99 | 76010015000 REAR WHEEL REPAIR KIT DUKE | REAR WHEEL REPAIR KIT DUKE | — | — | Check availability | |
| 29 | 21009098000 Rim logo HQV | Rim logo HQV | 2 | — | Check availability |
