CYLINDER HEAD
Parts (38)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | C90036220100C1 Cylinder head cpl. | Cylinder head cpl. | 1 | $626.11 | Available | 1 |
| 3 | C0402050980 needle roller DIN 5402 5x9.8 | needle roller DIN 5402 5x9.8 | 2 | $1.99 | Backorder — Restocking | 2 |
| 4 | C90030063050 oil jet 50 M5 | oil jet 50 M5 | 8 | $3.99 | Backorder — Restocking | 8 |
| 5 | C90036052010 Decoupling element | Decoupling element | 1 | $1.99 | Available | 1 |
| 6 | C90036055000 valve mechanism cover screw | valve mechanism cover screw | 1 | $4.99 | Available | 1 |
| 7 | C0000250605500 HH collar screw M6x55 TX30 | HH collar screw M6x55 TX30 | 2 | $0.99 | Available | 2 |
| 8 | 0025060405 HH collar screw M6x40 ISA30 | HH collar screw M6x40 ISA30 | 16 | $1.99 | Available | 16 |
| 9 | 0906100100 pipe plug DIN 906 M10x1 | pipe plug DIN 906 M10x1 | 1 | $4.99 | Available | 1 |
| 10 | 61238091100 oil pressure switch ''BITRON'' | oil pressure switch ''BITRON'' | 1 | $39.37 | Available | 1 |
| 11 | C07700900151 O-RING 9x1,5 V80 SH | O-RING 9x1,5 V80 SH | 1 | $1.99 | Available | 1 |
| 12 | C90035047000 water temperature sensor | water temperature sensor | 1 | $25.07 | Available | 1 |
| 13 | C0770100020 o-ring 10.00x2.00 silicone | o-ring 10.00x2.00 silicone | 1 | $1.99 | Available | 1 |
| 14 | C0908120153 screw M12x1,5 | screw M12x1,5 | 1 | $1.99 | Available | 1 |
| 15 | C90030036300 Cylinder head gasket | Cylinder head gasket | 1 | $3.99 | Available | 1 |
| 16 | C58530014100 dowl sleeve 10.2x12.5x10 | dowl sleeve 10.2x12.5x10 | 2 | $2.99 | Available | 2 |
| 17 | C90035117000 Thermostat BING 205-66 | Thermostat BING 205-66 | 1 | $32.99 | Available | 1 |
| 18 | C63635019000 Water connection | Water connection | 1 | $19.35 | Backorder — Restocking | 1 |
| 19 | C0000250501600S HH Collar Screw M5x16 ISA30 SS | HH Collar Screw M5x16 ISA30 SS | 3 | $1.99 | Available | 3 |
| 20 | C78630044000 cylinder head bolt M10x1.25 L= | cylinder head bolt M10x1.25 L= | 6 | $13.52 | Available | 6 |
| 21 | C90036089010 washer 19x10.5x2.5 | washer 19x10.5x2.5 | 6 | $1.99 | Backorder — Restocking | 6 |
| 22 | C90036144000 Intake sleeve | Intake sleeve | 2 | $33.21 | Backorder — Restocking | 2 |
| 23 | C61236048000 hose clamp Gemi 66 | hose clamp Gemi 66 | 4 | $8.02 | Available | 4 |
| 24 | C0770298178 O-RING 29,87X1,78 VITON | O-RING 29,87X1,78 VITON | 4 | $1.99 | Backorder — Restocking | 4 |
| 25 | C63536075000 spark plug shaft insert | spark plug shaft insert | 2 | $24.74 | Available | 2 |
| 26 | C90036075050 spark plug shaft gasket | spark plug shaft gasket | 2 | $6.15 | Available | 2 |
| 27 | C90036053000 Valve cover seal | Valve cover seal | 1 | $15.94 | Available | 1 |
| 28 | C9003605200033 valve cover | valve cover | 1 | $20.01 | Backorder — Restocking | 1 |
| 29 | C90036054160 RUBBER GASKET FOR SCREW | RUBBER GASKET FOR SCREW | 4 | $3.99 | Available | 4 |
| 30 | C90036054150 Valve cover screw | Valve cover screw | 4 | $3.99 | Available | 4 |
| 31 | C0770012030 O-RING 12,00X3,0 VITON 75 | O-RING 12,00X3,0 VITON 75 | 1 | $1.99 | Available | 1 |
| 32 | C63536081000 Bleeder connector | Bleeder connector | 1 | $2.99 | Available | 1 |
| 33 | C90036082150 connecting angle retaining pla | connecting angle retaining pla | 1 | $1.99 | Available | 1 |
| 34 | C0000250601200 HH collar screw M6x12 TX30 | HH collar screw M6x12 TX30 | 1 | $0.99 | Available | 1 |
| 35 | 00050198706 VARIABLE ONE-EAR CLAMP 19,8MM | VARIABLE ONE-EAR CLAMP 19,8MM | 1 | — | Obsolete | View Details |
| 36 | C90030387000 enigne breather hose | enigne breather hose | 1 | $40.25 | Backorder — Restocking | 1 |
| 37 | C90038016000 Oil screen | Oil screen | 1 | $7.58 | Available | 1 |
| 38 | 63641038000 Knock control sensor | Knock control sensor | 1 | $85.13 | Available | 1 |
| 39 | C0000250803000 HH collar screw M8x30 | HH collar screw M8x30 | 1 | $0.99 | Available | 1 |
