TIMING DRIVE
Parts (16)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 79036009000 CAMSHAFT INTAKE | CAMSHAFT INTAKE | 1 | $244.41 | Available | 1 |
| 2 | 79036010100 Camshaft Exhaust Valve | Camshaft Exhaust Valve | 1 | $196.34 | Available | 1 |
| 3 | 79236004000 TIMING CHAIN GUIDE TOP | TIMING CHAIN GUIDE TOP | 1 | $36.73 | Available | 1 |
| 4 | 79236001000 GUIDE RAIL | GUIDE RAIL | 1 | $14.84 | Available | 1 |
| 5 | 79236002000 TENSIONING RAIL | TENSIONING RAIL | 1 | $25.29 | Available | 1 |
| 6 | 77236001160 BUSHING SCREW M6 | BUSHING SCREW M6 | 2 | $6.15 | Available | 2 |
| 7 | 77236002160 BUSHING SCREW M8 | BUSHING SCREW M8 | 1 | $3.99 | Available | 1 |
| 8 | 0770180020 o-ring 18.00x2.00 NBR70 | o-ring 18.00x2.00 NBR70 | 1 | $2.99 | Available | 1 |
| 9 | 77036003000 CHAIN ADJUSTER HYD. 05 | CHAIN ADJUSTER HYD. 05 | 1 | $86.89 | Available | 1 |
| 10 | 0603242920 CU SEAL-RING DIN7603 A24X29X2 | CU SEAL-RING DIN7603 A24X29X2 | 1 | $3.99 | Available | 1 |
| 11 | 77336008000 HOLDING BOLT M24X1,5 | HOLDING BOLT M24X1,5 | 1 | $24.19 | Available | 1 |
| 12 | 0770010010 o-ring 10.00x1.00 NBR70 | o-ring 10.00x1.00 NBR70 | 1 | $2.99 | Available | 1 |
| 13 | 77236080100 threaded plug | threaded plug | 1 | $7.80 | Available | 1 |
| 14 | 77236081000 ANGLE PIECE F. BREATHER SYSTEM | ANGLE PIECE F. BREATHER SYSTEM | 1 | $4.99 | Available | 1 |
| 15 | 77236005000 SECURING PROTECTION | SECURING PROTECTION | 1 | $3.99 | Available | 1 |
| 16 | 79236013100 TIMING CHAIN | TIMING CHAIN | 1 | $124.62 | Available | 1 |
