SHOCK ABSORBER DISASSEMBLED
Parts (30)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 46181242S6 Monoshock case M53x1 with pipe | Monoshock case M53x1 with pipe | 1 | $345.39 | Available | 1 |
| 2 | 36120151S PLUG SCREW M5X6 CPL. | PLUG SCREW M5X6 CPL. | 1 | $4.83 | Available | 1 |
| 3 | 46810893 O-ring 5,28x1,78 NBR70 black | O-ring 5,28x1,78 NBR70 black | 1 | $0.76 | Available | 1 |
| 4 | 50180095 HS cylinder-head screw R1/8 l8 | HS cylinder-head screw R1/8 l8 | 1 | $2.85 | Available | 1 |
| 5 | RP10011 Ball joint bearing kit 12mm | Ball joint bearing kit 12mm | 2 | $83.79 | Available | 2 |
| 6 | 52000230 Sticker XACT 85 SX | Sticker XACT 85 SX | 1 | $37.94 | Available | 1 |
| 7 | 50181101S40 Compression cpl. | Compression cpl. | 1 | $109.55 | Out of Stock | Notify Me |
| 8 | 50180217 O-ring 27x1,5 Viton70 green IS | O-ring 27x1,5 Viton70 green IS | 1 | $2.41 | Available | 1 |
| 9 | 91010271S SPRING (59) 215 30 N/MM | SPRING (59) 215 30 N/MM | — | $153.99 | Available | 1 |
| 9 | 91010240S Spring (59) 215 35 N/MM D=9.25 | Spring (59) 215 35 N/MM D=9.25 | — | $153.99 | Available | 1 |
| 9 | 91010161S SPRING (59) 215 40 N/MM D=9,5 | SPRING (59) 215 40 N/MM D=9,5 | 1 | $153.99 | Available | 1 |
| 9 | 91010201 Mainspring (59) 45-215 damper | Mainspring (59) 45-215 damper | — | $153.99 | Available | 1 |
| 9 | 91010080 Mainspring (59) 50-215 damper | Mainspring (59) 50-215 damper | — | $153.99 | Available | 1 |
| 9 | 91010170S SPRING 55 N/MM | SPRING 55 N/MM | — | $153.99 | Available | 1 |
| 10 | 46181382S Plastic Spring Retainer D46 cp | Plastic Spring Retainer D46 cp | 1 | $38.27 | Available | 1 |
| 11 | RP10005 SPRING CUP SET PDS 17 | SPRING CUP SET PDS 17 | 1 | $38.27 | Available | 1 |
| 12 | 46810010 Round-wire snap ring 49x1,5 | Round-wire snap ring 49x1,5 | 1 | $3.62 | Available | 1 |
| 13 | 46181351 Cover 46,12x15 h5,5 red | Cover 46,12x15 h5,5 red | 1 | $32.55 | Available | 1 |
| 14 | 46181237 Rubber pad 17x48x55 | Rubber pad 17x48x55 | 1 | $22.76 | Available | 1 |
| 15 | 46181301S3 Bottom part M18x1 h54,5 cpl. | Bottom part M18x1 h54,5 cpl. | 1 | $309.42 | Available | 1 |
| 17 | 46180669S Sealholder 46x28 cpl. | Sealholder 46x28 cpl. | 1 | $83.81 | Backorder — Restocking | 1 |
| 18 | 46181365S Nut PDS M10x1 h17,2 WAF19 cpl. | Nut PDS M10x1 h17,2 WAF19 cpl. | 1 | $67.53 | Available | 1 |
| 19 | 46181416 Piston 15,4x35,4x6 | Piston 15,4x35,4x6 | 1 | $16.49 | Available | 1 |
| 20 | 46181561 Bushing 10x17x21 | Bushing 10x17x21 | 1 | $7.03 | Available | 1 |
| 21 | 46810474 Piston rod nut M12x1 | Piston rod nut M12x1 | 1 | $6.15 | Available | 1 |
| 22 | 46811258 Washer 12x24x2,5 | Washer 12x24x2,5 | 1 | $29.14 | Backorder — Restocking | 1 |
| 23 | 46181328S Piston 12x46x20 cpl. | Piston 12x46x20 cpl. | 1 | $80.29 | Available | 1 |
| 24 | 46181194 Rebound disc 12x36x4 h0 | Rebound disc 12x36x4 h0 | 1 | $15.17 | Available | 1 |
| 98 | 50180751S1 SHOCK ABSORBER FLUID 5 LT | SHOCK ABSORBER FLUID 5 LT | 1 | $175.99 | Available | 1 |
| 99 | RP10020 Repairing kit shock absorber P | Repairing kit shock absorber P | 1 | $142.99 | Available | 1 |
