CLUTCH
Parts (18)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 0912050163 AH collar screw DIN 912 M5x16 | AH collar screw DIN 912 M5x16 | 3 | — | Check availability | |
| 2 | 47232006100 Spring retainer | Spring retainer | 1 | — | Check availability | |
| 3 | 47232005000 Clutch spring 58x97.1x1.5 | Clutch spring 58x97.1x1.5 | 1 | — | Check availability | |
| 4 | 47232013000 Inner ring 94x99x1.5 | Inner ring 94x99x1.5 | 1 | — | Check availability | |
| 5 | 47232003100 Clutch pressure plate | Clutch pressure plate | 1 | — | Check availability | |
| 6 | 78132057144 PRESSURE PIECE CPL. | PRESSURE PIECE CPL. | 1 | — | Check availability | |
| 8 | 47232011000 lining disc 1,95mm | lining disc 1,95mm | 7 | — | Check availability | |
| 9 | 47232010033 disc pack | disc pack | 1 | — | Check availability | |
| 10 | 50532004100 Sleeve 7.95x31.65 | Sleeve 7.95x31.65 | 6 | — | Check availability | |
| 11 | 47232019000 Hexagon nut M16x1,5 | Hexagon nut M16x1,5 | 1 | — | Check availability | View Details |
| 12 | 47232018100 Lock washer | Lock washer | 1 | — | Check availability | |
| 13 | 47232102100 Inner clutch hub | Inner clutch hub | 1 | — | Check availability | |
| 14 | 47232017000 Support disk | Support disk | 1 | — | Check availability | |
| 15 | 47232001164 clutch basket | clutch basket | 1 | — | Check availability | |
| 16 | 0405263017 Needle cage K263017 | Needle cage K263017 | 1 | — | Check availability | |
| 17 | 47232015000 Collar 20x26x19 | Collar 20x26x19 | 1 | — | Check availability | |
| 18 | 47232054000 Rod | Rod | 1 | — | Check availability | |
| 19 | 47232023020 Gear primary drive | Gear primary drive | 1 | — | Check availability |
