SHIFTING MECHANISM
Parts (31)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 47234005044 Shift shaft cpl. | Shift shaft cpl. | 1 | $75.56 | Available | 1 |
| 2 | 0471140100 retaining ring DIN 471 14x1 | retaining ring DIN 471 14x1 | 1 | $1.99 | Available | 1 |
| 3 | 54634050000 STOP DISK 14X30X1 | STOP DISK 14X30X1 | 1 | $2.99 | Available | 1 |
| 4 | 54834014000 RETURN SPRING 03 | RETURN SPRING 03 | 1 | $4.99 | Available | 1 |
| 5 | 54634020000 SPRING GUIDE | SPRING GUIDE | 1 | $7.58 | Available | 1 |
| 6 | 79234008144 SLIDING PLATE CPL. | SLIDING PLATE CPL. | 1 | $41.79 | Available | 1 |
| 7 | 56534013100 TENSIONING SPRING 0,8MM | TENSIONING SPRING 0,8MM | 1 | $1.99 | Available | 1 |
| 8 | 49033013000 STOP DISK 12,1X25X1 | STOP DISK 12,1X25X1 | 1 | $4.99 | Available | 1 |
| 9 | 46034027000 NEEDLE BEARING 12X18X12 2002 | NEEDLE BEARING 12X18X12 2002 | 2 | $9.45 | Available | 2 |
| 10 | 0760122050 SHAFT SEAL RING 12X20X5 B | SHAFT SEAL RING 12X20X5 B | 1 | $9.45 | Available | 1 |
| 11 | 50434031000 SHIFT LEVER CPL. | SHIFT LEVER CPL. | 1 | $109.00 | Available | 1 |
| 12 | 50233041500 PAIR NORDLOCK WASHER M6 | PAIR NORDLOCK WASHER M6 | 1 | $4.99 | Available | 1 |
| 13 | 0024060156S HH collar screw M6x15 TX30 | HH collar screw M6x15 TX30 | 1 | $2.99 | Available | 1 |
| 14 | 0025050206S Hex collar screw, M5x20 ISA30 | Hex collar screw, M5x20 ISA30 | 1 | $1.99 | Available | 1 |
| 15 | 0349000050 WASHER DIN7349-5X15X2 | WASHER DIN7349-5X15X2 | 1 | $1.99 | Available | 1 |
| 16 | 55434024000 LOCKING LEVER CPL. | LOCKING LEVER CPL. | 1 | $47.84 | Available | 1 |
| 17 | 54634052300 SLEEVE FOR LOCKING LEVER | SLEEVE FOR LOCKING LEVER | 1 | $3.99 | Available | 1 |
| 18 | 50334023000 LOCATING LEVER SPRING 2,5MM'98 | LOCATING LEVER SPRING 2,5MM'98 | 1 | $4.99 | Available | 1 |
| 19 | 47234002000 Shift fork 1.-4. gear | Shift fork 1.-4. gear | 1 | $32.22 | Available | 1 |
| 20 | 47234003000 Shift fork 2.-3. gear | Shift fork 2.-3. gear | 1 | $32.22 | Available | 1 |
| 21 | 0402061480 NEEDLE ROLLER DIN5402 6X14,8 | NEEDLE ROLLER DIN5402 6X14,8 | 3 | $4.99 | Available | 3 |
| 22 | 47234019000 Shift rail 11.8x80x8mm | Shift rail 11.8x80x8mm | 1 | $9.56 | Available | 1 |
| 23 | 58038023200 PRESSURE SPRING 0,9MM | PRESSURE SPRING 0,9MM | 3 | $4.99 | Available | 3 |
| 24 | 0012060303S Cap head screw M6x30-8.8 | Cap head screw M6x30-8.8 | 1 | $1.99 | Available | 1 |
| 25 | 79234015100 Shift star cmpl | Shift star cmpl | 1 | $30.35 | Available | 1 |
| 26 | 0625618050 BALL BEARING 61805 C3 | BALL BEARING 61805 C3 | 1 | $51.69 | Available | 1 |
| 27 | 47234012044 Shift drum cpl. | Shift drum cpl. | 1 | $64.89 | Available | 1 |
| 29 | 47234001000 Shift fork 5.-6. gear | Shift fork 5.-6. gear | 1 | $32.33 | Available | 1 |
| 30 | 46234020000 SHIFTING RAIL MAIN SHAFT | SHIFTING RAIL MAIN SHAFT | 1 | $16.60 | Available | 1 |
| 31 | 54634049000 RETAINING PLATE | RETAINING PLATE | 1 | $4.99 | Available | 1 |
| 32 | 0025060126 HH collar screw M6x12 TX30 | HH collar screw M6x12 TX30 | 1 | $3.99 | Available | 1 |
