CYLINDER, CYLINDER HEAD
Parts (36)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 50430079000 CYLINDER HEAD SCREW | CYLINDER HEAD SCREW | 4 | $3.99 | Available | 4 |
| 2 | 0603070121 CU-SEAL RING DIN7603- 7,3X12X1 | CU-SEAL RING DIN7603- 7,3X12X1 | 4 | $1.99 | Available | 4 |
| 3 | 46230006100 Cylinder head | Cylinder head | 1 | $153.22 | Available | 1 |
| 4 | 45230036000 CYLINDER HEAD GASKET | CYLINDER HEAD GASKET | 1 | $4.99 | Available | 1 |
| 5 | 46030045000 flanged nut M8 WS10 | flanged nut M8 WS10 | 4 | $9.23 | Available | 4 |
| 6 | 0402040980 Needle roll.DIN5402 NRB 4X9.8 | Needle roll.DIN5402 NRB 4X9.8 | 2 | $3.99 | Available | 2 |
| 7 | 46230138000 Cylinder + piston | Cylinder + piston | 1 | $577.49 | Available | 1 |
| 8 | A40530035020 Cylinder base gasket | Cylinder base gasket | — | $4.99 | Available | 1 |
| 8 | A40530035025 Cylinder base gasket | Cylinder base gasket | — | $4.99 | Available | 1 |
| 8 | A40530035040 Cylinder base gasket | Cylinder base gasket | — | $4.99 | Available | 1 |
| 8 | A40530035050 Cylinder base gasket | Cylinder base gasket | — | $5.05 | Available | 1 |
| 9 | 46205004000 EXHAUST PIPE FLANGE GASKET | EXHAUST PIPE FLANGE GASKET | 1 | $9.89 | Available | 1 |
| 10 | 46305003000 Exhaust flange 65 | Exhaust flange 65 | 1 | $28.37 | Available | 1 |
| 11 | 46205003050 BRACKET FOR SPRINGHOLDER | BRACKET FOR SPRINGHOLDER | 1 | $18.03 | Available | 1 |
| 12 | 0025060306S HH collar screw M6x30 TX30 | HH collar screw M6x30 TX30 | 3 | $3.99 | Available | 3 |
| 17 | 58336020190 VACUUM CONECTION M6/3MM '97 | VACUUM CONECTION M6/3MM '97 | 1 | $6.15 | Available | 1 |
| 18 | 59007017000 CLAMP YDNAC 10096F (9,6MM) | CLAMP YDNAC 10096F (9,6MM) | 2 | $2.99 | Available | 2 |
| 19 | A40537014000 Exhaust control hose | Exhaust control hose | 1 | $11.79 | Backorder — Late August 2026 | 1 |
| 30 | 46237036044 VENTILATION CPL. | VENTILATION CPL. | 1 | $13.08 | Available | 1 |
| 31 | 0014050163 HH COLLAR SCREW M 5X16 WS=6 | HH COLLAR SCREW M 5X16 WS=6 | 3 | $2.99 | Available | 3 |
| 32 | 46337035000 Closing cover | Closing cover | 1 | $18.36 | Available | 1 |
| 33 | 0985050003 Self locking nut DIN 985 M5 | Self locking nut DIN 985 M5 | 1 | $2.99 | Available | 1 |
| 34 | 46237013000 MEMBRANE | MEMBRANE | 1 | $51.47 | Available | 1 |
| 35 | 46337011000 Flange, exhaust control | Flange, exhaust control | 1 | $36.29 | Available | 1 |
| 36 | 0770030015 O-RING 3,00X1,50 NBR 70 | O-RING 3,00X1,50 NBR 70 | 2 | $2.99 | Available | 2 |
| 37 | 0770150151 O-RING 15,00X1,50 VITON | O-RING 15,00X1,50 VITON | 1 | $3.99 | Available | 1 |
| 38 | 46237074100 ADJ. SPRING - EXHAUST CONTROL | ADJ. SPRING - EXHAUST CONTROL | 1 | $3.99 | Available | 1 |
| 40 | 46337020033 OUTLET VALVE CPL. | OUTLET VALVE CPL. | 1 | $76.77 | Available | 1 |
| 42 | 0912050083 SHCS DIN 912 M5x8 | SHCS DIN 912 M5x8 | 1 | $1.99 | Available | 1 |
| 43 | 0012060303S Cap head screw M6x30-8.8 | Cap head screw M6x30-8.8 | 1 | $1.99 | Available | 1 |
| 44 | 0603061001 CU-SEAL RING DIN7603-6X10X1 | CU-SEAL RING DIN7603-6X10X1 | 1 | $2.99 | Available | 1 |
| 45 | 0603050901 COPPERT GASKET 5X9X1 | COPPERT GASKET 5X9X1 | 1 | $2.99 | Available | 1 |
| 99 | A40530007010 I piston kit I 65 SX/TC/MC | piston kit I 65 SX/TC/MC | — | $221.09 | Available | 1 |
| 99 | A40530007010 II piston kit II 65 SX/TC/MC | piston kit II 65 SX/TC/MC | — | $221.09 | Available | 1 |
| 8 | A40530035060 Cylinder base gasket | Cylinder base gasket | — | $5.49 | Available | 1 |
| 8 | A40530035030 Cylinder base gasket | Cylinder base gasket | — | $3.99 | Available | 1 |
