FRONT FORK DISASSEMBLED
Parts (18)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 35480455S3 AXLE CLAMP R/S CPL. W. TUBE | AXLE CLAMP R/S CPL. W. TUBE | 1 | — | Check availability | |
| 2 | 35480456S2 AXLE CLAMP L/S CPL. W. TUBE | AXLE CLAMP L/S CPL. W. TUBE | 1 | — | Check availability | |
| 3 | 35480564 Fork outer tube 36x465 dt44 db | Fork outer tube 36x465 dt44 db | 2 | — | Check availability | |
| 4 | 95010051S SPRING 2.0N/MM SET D=3.1MM | SPRING 2.0N/MM SET D=3.1MM | 1 | — | Check availability | |
| 5 | 35480497 Washer 22x30x2,5 | Washer 22x30x2,5 | 3 | — | Check availability | |
| 6 | 35480548S Screw cap M38x1,5 air cpl. | Screw cap M38x1,5 air cpl. | 1 | — | Check availability | |
| 7 | 35480507S1 Screw cap M38x1,5 air rebound | Screw cap M38x1,5 air rebound | 1 | — | Check availability | |
| 8 | 46180581 O-ring 35x1,5 NBR70 yellow | O-ring 35x1,5 NBR70 yellow | 2 | — | Check availability | |
| 9 | 48601494S Schrader valve M8x1 cmpl. | Schrader valve M8x1 cmpl. | 1 | — | Check availability | View Details |
| 10 | 00600003 ISA countersunk head screw M4x | ISA countersunk head screw M4x | 1 | — | Check availability | View Details |
| 11 | 48601118S ADJUSTER REB. RED CPL. | ADJUSTER REB. RED CPL. | 1 | — | Check availability | View Details |
| 12 | 35480551S2 PISTON ROD SX 50 CPL. RIGHT | PISTON ROD SX 50 CPL. RIGHT | 1 | — | Check availability | |
| 13 | 35480551S3 PISTON ROD SX 50 CPL. LEFT | PISTON ROD SX 50 CPL. LEFT | 1 | — | Check availability | |
| 14 | 48601166S1 Fork Fluid Viscosity 4.0 5L | Fork Fluid Viscosity 4.0 5L | 1 | — | Check availability | |
| 97 | RP10006 BUSHING KIT 35MM | BUSHING KIT 35MM | — | — | Check availability | View Details |
| 98 | RP10007 GASKET KIT 35MM RED | GASKET KIT 35MM RED | — | — | Check availability | View Details |
| 99 | RP10008 REPAIR KIT 50+65SX AIR 2017 | REPAIR KIT 50+65SX AIR 2017 | — | — | Check availability | View Details |
| 96 | 00062010053 special grease AER Fork 400g | special grease AER Fork 400g | 1 | — | Check availability |
