FRONT FORK DISASSEMBLED
Parts (25)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 35480455S3 AXLE CLAMP R/S CPL. W. TUBE | AXLE CLAMP R/S CPL. W. TUBE | 1 | $384.55 | Available | 1 |
| 2 | 35480456S2 AXLE CLAMP L/S CPL. W. TUBE | AXLE CLAMP L/S CPL. W. TUBE | 1 | $390.60 | Available | 1 |
| 3 | 35480585 Fork outer tube 36x425 dt42 db | Fork outer tube 36x425 dt42 db | 2 | $196.12 | Available | 2 |
| 4 | 95010055S SPRING 1,8 N/MM SET | SPRING 1,8 N/MM SET | — | $153.99 | Available | 1 |
| 4 | 95010051S SPRING 2.0N/MM SET D=3.1MM | SPRING 2.0N/MM SET D=3.1MM | 1 | $153.99 | Available | 1 |
| 4 | 95010052S SPRING 2,2 N/MM SET | SPRING 2,2 N/MM SET | — | $153.99 | Available | 1 |
| 5 | 35480497 Washer 22x30x2,5 | Washer 22x30x2,5 | — | $1.20 | Available | 1 |
| 6 | 35480599S Screw cap M38x1,5 air d42 cpl. | Screw cap M38x1,5 air d42 cpl. | 1 | $97.01 | Available | 1 |
| 7 | 35480600S Screw cap M38x1,5 d42 cpl. | Screw cap M38x1,5 d42 cpl. | 1 | $96.79 | Available | 1 |
| 8 | 46180581 O-ring 35x1,5 NBR70 yellow | O-ring 35x1,5 NBR70 yellow | 2 | $2.41 | Available | 2 |
| 9 | 48601494S Schrader valve M8x1 cmpl. | Schrader valve M8x1 cmpl. | 1 | $29.39 | Backorder — Restocking | 1 |
| 11 | RP10021 Adjuster kit screw cap | Adjuster kit screw cap | 1 | $6.70 | Available | 1 |
| 12 | 35480551S6 pistonrod cpl. Right | pistonrod cpl. Right | 1 | $284.78 | Available | 1 |
| 13 | 35480551S7 pistonrodcpl. Left | pistonrodcpl. Left | 1 | $255.08 | Available | 1 |
| 14 | 52000313 Sticker warning 60x40 | Sticker warning 60x40 | 1 | $29.47 | Available | 1 |
| 15 | 52000223SET Sticker set XACT AER 140x141 | Sticker set XACT AER 140x141 | 1 | $37.61 | Available | 1 |
| 16 | 35480583 Stroke indicator d35 red | Stroke indicator d35 red | 2 | $4.83 | Available | 2 |
| 17 | 35480623 Fork protection ring 48,4mm | Fork protection ring 48,4mm | 2 | $2.41 | Available | 2 |
| 18 | 0025060256 HH collar screw M6x25 TX30 | HH collar screw M6x25 TX30 | 2 | $3.99 | Available | 2 |
| 94 | 48601166S1 Fork Fluid Viscosity 4.0 5L | Fork Fluid Viscosity 4.0 5L | — | $175.99 | Available | 1 |
| 95 | T14034 Fuchs grease IPR (250g) | Fuchs grease IPR (250g) | — | $40.69 | Available | 1 |
| 96 | 00062010053 special grease AER Fork 400g | special grease AER Fork 400g | — | $99.54 | Available | 1 |
| 97 | RP10006 BUSHING KIT 35MM | BUSHING KIT 35MM | — | $35.52 | Available | 1 |
| 98 | RP10027 gasket kit 35mm black | gasket kit 35mm black | — | $66.98 | Available | 1 |
| 99 | RP10008 REPAIR KIT 50+65SX AIR 2017 | REPAIR KIT 50+65SX AIR 2017 | — | $49.16 | Available | 1 |
