FRAME
Parts (23)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 4540300100069 Frame 454T3 | Frame 454T3 | 1 | $1385.33 | Out of Stock | Notify Me |
| 2 | 54310086200 Self locking nut M8 10.9 | Self locking nut M8 10.9 | 1 | $3.99 | Available | 1 |
| 3 | 01665080806 Hexagonal bolt EN 1665-M8x80-1 | Hexagonal bolt EN 1665-M8x80-1 | 1 | $1.99 | Available | 1 |
| 4 | 45303053000 Chain slider bottom | Chain slider bottom | 1 | $11.87 | Available | 1 |
| 7 | 0025080306 HH collar screw M8x30 | HH collar screw M8x30 | 1 | $3.62 | Available | 1 |
| 8 | 47103040033 FOOTREST CPL. 14 | FOOTREST CPL. 14 | 1 | $129.57 | Available | 1 |
| 9 | 47103040000 FOOTREST L/S | FOOTREST L/S | 1 | $51.58 | Available | 1 |
| 10 | 47103041000 FOOTREST R/S | FOOTREST R/S | 1 | $50.26 | Available | 1 |
| 11 | 54803044000 PIN FOR FOOT PED 51.5X9.8 MM | PIN FOR FOOT PED 51.5X9.8 MM | 2 | $14.62 | Available | 2 |
| 12 | 54603041000 FOOTREST SPRING L/S & R/S | FOOTREST SPRING L/S & R/S | 2 | $6.15 | Available | 2 |
| 13 | 0125100003 washer DIN 125 A 10.5 | washer DIN 125 A 10.5 | 2 | $2.99 | Available | 2 |
| 14 | 0094032253 PIN DIN0094-3,2X25 STEEL | PIN DIN0094-3,2X25 STEEL | 2 | $1.99 | Available | 2 |
| 15 | 76006014000 rubber grommet | rubber grommet | 2 | $1.99 | Available | 2 |
| 16 | 45403002010 Subframe left | Subframe left | 1 | $41.13 | Available | 1 |
| 17 | 45403002020 Subframe right | Subframe right | 1 | $41.13 | Available | 1 |
| 18 | 45403083000 Frame cover left | Frame cover left | 1 | $13.30 | Available | 1 |
| 19 | 45403084000 Frame cover right | Frame cover right | 1 | $14.07 | Available | 1 |
| 20 | 45403096000 Failure protection | Failure protection | 1 | $23.53 | Available | 1 |
| 21 | 0035080206S SHCS M8x20 TX45 | SHCS M8x20 TX45 | 4 | $6.26 | Available | 4 |
| 22 | 0017060255 EJOT PT SCREW K60X25-Z SW6 | EJOT PT SCREW K60X25-Z SW6 | 1 | $3.99 | Available | 1 |
| 23 | 0025060256 HH collar screw M6x25 TX30 | HH collar screw M6x25 TX30 | 1 | $3.99 | Available | 1 |
| 6 | 0025080166 HH COLLAR SCREW M8X16 TX40 | HH COLLAR SCREW M8X16 TX40 | 1 | $4.99 | Available | 1 |
| 24 | 41001052000 RUBBER SLEEVE D=12MM | RUBBER SLEEVE D=12MM | 2 | $4.99 | Available | 2 |
