INSTRUMENTS / LOCK SYSTEM
Parts (47)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 0912080753 AH SCREW DIN0912-M 8X75 | AH SCREW DIN0912-M 8X75 | 2 | — | Obsolete | View Details |
| 2 | 0125080003 washer DIN 125 A -8.4 | washer DIN 125 A -8.4 | 2 | $1.99 | Available | 2 |
| 3 | 0985080003 SELF LOCKING NUT DIN0985-M 8 | SELF LOCKING NUT DIN0985-M 8 | 2 | $2.99 | Available | 2 |
| 4 | 76712089000 navigation tower | navigation tower | 1 | — | Obsolete | View Details |
| 5 | 76712091100 Carrier for roadbook bracket Z | Carrier for roadbook bracket Z | 1 | — | Out of Stock | Notify Me |
| 6 | 0471140100 retaining ring DIN 471 14x1 | retaining ring DIN 471 14x1 | 6 | $1.99 | Available | 6 |
| 7 | 81214086000 INDICATOR LIGHT RESERVE | INDICATOR LIGHT RESERVE | 2 | $9.01 | Available | 2 |
| 8 | 58011022400 TEMPERATURE WARN. LIGHT RED'98 | TEMPERATURE WARN. LIGHT RED'98 | 1 | $7.69 | Out of Stock | Notify Me |
| 9 | 58011021300 H.BEAM INDICATOR LIGHT BLUE'98 | H.BEAM INDICATOR LIGHT BLUE'98 | 1 | $7.80 | Available | 1 |
| 10 | 58011025000 OIL INDICATOR LIGHT RED | OIL INDICATOR LIGHT RED | 1 | $7.58 | Available | 1 |
| 11 | 58011024300 FLASHER INDICAT.LIGHT GREEN'98 | FLASHER INDICAT.LIGHT GREEN'98 | 1 | $7.91 | Available | 1 |
| 12 | 54603048100 clip nut M6 | clip nut M6 | 4 | $4.99 | Available | 4 |
| 13 | 31008060000 rubber grommet D=8mm open | rubber grommet D=8mm open | 4 | $2.99 | Available | 4 |
| 14 | 76712073000 ICO retaining bracket ASSY | ICO retaining bracket ASSY | 1 | — | Out of Stock | Notify Me |
| 15 | 76408001004 BUSHING | BUSHING | 2 | — | Obsolete | View Details |
| 16 | 76712069000 ICO connector plate ASSY | ICO connector plate ASSY | 1 | — | Out of Stock | Notify Me |
| 17 | 0025060126 HH collar screw M6x12 TX30 | HH collar screw M6x12 TX30 | 6 | $3.99 | Available | 6 |
| 18 | 76712069020 ICO plug sheet | ICO plug sheet | 1 | — | Obsolete | View Details |
| 19 | 0024060136 HH collar screw M6x13 TX30 | HH collar screw M6x13 TX30 | 4 | $3.99 | Available | 4 |
| 20 | 0024060106 HH COLLAR SCREW M6X10 TX30 | HH COLLAR SCREW M6X10 TX30 | 4 | $3.99 | Available | 4 |
| 21 | 0985050003 Self locking nut DIN 985 M5 | Self locking nut DIN 985 M5 | 2 | $2.99 | Available | 2 |
| 22 | 43205062100 silentbloc 20x15-M6x10-(1) | silentbloc 20x15-M6x10-(1) | 8 | $16.38 | Available | 8 |
| 23 | 76712092000 Bracket GPS | Bracket GPS | 2 | — | Out of Stock | Notify Me |
| 24 | 0926060000 STOP NUT M6 DIN6926 A2-70 | STOP NUT M6 DIN6926 A2-70 | 2 | $3.99 | Available | 2 |
| 25 | 76712092030 Strap | Strap | 2 | — | Out of Stock | Notify Me |
| 27 | 0025050106 HH collar screw M5x10 TX30 | HH collar screw M5x10 TX30 | 2 | $1.99 | Available | 2 |
| 34 | 76712075044 Roadbook switch cmpl. | Roadbook switch cmpl. | 1 | — | Obsolete | View Details |
| 35 | 0912060163 AH SCREW DIN0912-M 6X16 | AH SCREW DIN0912-M 6X16 | 4 | $1.99 | Available | 4 |
| 40 | 76712098100 Roadbook | Roadbook | 1 | — | Out of Stock | Notify Me |
| 41 | 76712098150 Roadbook cover cmpl. | Roadbook cover cmpl. | 1 | — | Obsolete | View Details |
| 42 | 76712098193 Top handle | Top handle | 1 | — | Obsolete | View Details |
| 43 | 76712098192 Bottom grip | Bottom grip | 1 | — | Obsolete | View Details |
| 44 | 76712098195 O-ring 42x3 - NBR | O-ring 42x3 - NBR | 1 | — | Obsolete | View Details |
| 45 | 76712098191 Illumination LED | Illumination LED | 1 | — | Obsolete | View Details |
| 46 | 76712098194 Electric motor | Electric motor | 1 | — | Obsolete | View Details |
| 47 | 76712098144 Set of bushings | Set of bushings | 1 | — | Obsolete | View Details |
| 48 | 76712098190 Roadbook tool | Roadbook tool | 1 | — | Obsolete | View Details |
| 50 | 77714069600 Speedometer digital km/h f. 21 | Speedometer digital km/h f. 21 | 1 | $299.19 | Available | 1 |
| 51 | 0081645121 EJOT DELTA PT SCREW 45X12-Z | EJOT DELTA PT SCREW 45X12-Z | 2 | $1.99 | Available | 2 |
| 53 | 54814068100 CABLE FOR DIGITAL SPEEDOM. 06 | CABLE FOR DIGITAL SPEEDOM. 06 | 1 | $92.83 | Available | 1 |
| 60 | 76712085066 Tripmaster ICO kpl. | Tripmaster ICO kpl. | 1 | — | Out of Stock | Notify Me |
| 61 | 58512085160 BATTERY FOR ICO TRIPMASTER 04 | BATTERY FOR ICO TRIPMASTER 04 | 2 | $10.66 | Available | 2 |
| 62 | 76712085030 Wheel sensor, ICO tripmaster | Wheel sensor, ICO tripmaster | 1 | — | Out of Stock | Notify Me |
| 70 | 76712084020 Bracket Iritrack 2017 | Bracket Iritrack 2017 | 1 | — | Out of Stock | Notify Me |
| 73 | 0902060083 Oval head screw ISO 7380 M 6X8 | Oval head screw ISO 7380 M 6X8 | 4 | $1.99 | Available | 4 |
| 76 | 07985040103 Flat head screw DIN 7985 4.8 M | Flat head screw DIN 7985 4.8 M | 2 | — | Obsolete | View Details |
| 77 | 76712084002 Emergency transmitter sleeve | Emergency transmitter sleeve | 2 | — | Out of Stock | Notify Me |
