LIGHTING SYSTEM
Parts (31)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 76714001000 Hella M60 LED, low beam | Hella M60 LED, low beam | 1 | — | Check availability | |
| 2 | 76714002000 Hella M60 LED, high beam | Hella M60 LED, high beam | 1 | — | Check availability | |
| 4 | 76712089043 Windshield positioning pin | Windshield positioning pin | 2 | — | Check availability | |
| 6 | 76714040000 tail light | tail light | 1 | — | Check availability | |
| 7 | 75014047100 Number plate light | Number plate light | 1 | — | Check availability | |
| 8 | 78114025000 FLASHER CPL.FRONT L/S REAR R/S | FLASHER CPL.FRONT L/S REAR R/S | 2 | — | Check availability | |
| 9 | 78114026000 FLASHER CPL.FRONT R/S REAR L/S | FLASHER CPL.FRONT R/S REAR L/S | 2 | — | Check availability | |
| 10 | 60114027000 BULB 12V ORANGE (RY10W) | BULB 12V ORANGE (RY10W) | 4 | — | Check availability | |
| 11 | 0125100003 washer DIN 125 A 10.5 | washer DIN 125 A 10.5 | 4 | — | Check availability | |
| 12 | 58414030000 HH COLLAR NUT M10X1,25 WS=13 | HH COLLAR NUT M10X1,25 WS=13 | 4 | — | Check availability | |
| 13 | 0797100003 LOCK WASHER DIN6797-J10,5 ZI | LOCK WASHER DIN6797-J10,5 ZI | 4 | — | Check availability | |
| 15 | 76714040050 Extra rear light | Extra rear light | 1 | — | Check availability | |
| 18 | 76711080000 Wiring harness turn signal | Wiring harness turn signal | 1 | — | Check availability | |
| 20 | 76714004000 Position light | Position light | 1 | — | Check availability | |
| 21 | 0081050181 SCREW FOR PLASTIC K50X18 T20 | SCREW FOR PLASTIC K50X18 T20 | 3 | — | Check availability | |
| 22 | 0081250181 SCREW FOR PLASTIC 50X18 T20 | SCREW FOR PLASTIC 50X18 T20 | 1 | — | Check availability | |
| 23 | 0017060205 SCREW FOR PLASTIC K60X20 SW6 | SCREW FOR PLASTIC K60X20 SW6 | 2 | — | Check availability | |
| 24 | 76511078000 WIRING HARN. LIC. PLATE ILLUM. | WIRING HARN. LIC. PLATE ILLUM. | 1 | — | Check availability | |
| 25 | 49011435100 BULB 12V 5W (W2,1X9,5D) PHIL. | BULB 12V 5W (W2,1X9,5D) PHIL. | 1 | — | Check availability | |
| 26 | 0984050163S CYL. SCREW DIN6912 M5X16 8.8 | CYL. SCREW DIN6912 M5X16 8.8 | 8 | — | Check availability | |
| 27 | 45007040052 Clip | Clip | 2 | — | Check availability | |
| 29 | 76708004010 Windshield retaining bracket | Windshield retaining bracket | 1 | — | Check availability | |
| 32 | 49111425200 BULB 12V 2,3W (W2X4,6D) | BULB 12V 2,3W (W2X4,6D) | 6 | — | Check availability | |
| 33 | 76708001000 Headlight mask | Headlight mask | 1 | — | Check availability | |
| 34 | 76712079000 Stone chip guard | Stone chip guard | 1 | — | Check availability | |
| 35 | 76708001001 Rubber seal | Rubber seal | 1 | — | Check availability | |
| 36 | 78114028000 FLASHER LENS L/S R/S TRANSP. | FLASHER LENS L/S R/S TRANSP. | 2 | — | Check availability | |
| 37 | 78114027000 FLASHER LENS FRO.L/S-REAR R/S | FLASHER LENS FRO.L/S-REAR R/S | 2 | — | Check availability | |
| 39 | 76708003044 Light support structure | Light support structure | 1 | — | Check availability | |
| 40 | 0024060136 HH collar screw M6x13 TX30 | HH collar screw M6x13 TX30 | 10 | — | Check availability | |
| 17 | 0985050103 OVAL HEAD SCR. DIN7985-M 5X10 | OVAL HEAD SCR. DIN7985-M 5X10 | 2 | — | Check availability |
