CYLINDER, CYLINDER HEAD
Parts (31)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 55630038100 Cylinder + Piston cpl. 18 | Cylinder + Piston cpl. 18 | 1 | $1381.59 | Available | 1 |
| 2 | 55437001000 Connection Flange | Connection Flange | 1 | $366.40 | Available | 1 |
| 3 | 0912060353 AH SCREW DIN0912-M 6X35 | AH SCREW DIN0912-M 6X35 | 4 | $2.99 | Available | 4 |
| 4 | 54830079000 COLLAR SCREW M 8X35 WS=13 | COLLAR SCREW M 8X35 WS=13 | 6 | $4.99 | Available | 6 |
| 5 | 56530080000 CU-SEAL RING 8 X 16 X 1 | CU-SEAL RING 8 X 16 X 1 | 6 | $2.99 | Available | 6 |
| 6 | 79435047000 water temperature sensor | water temperature sensor | 1 | $27.93 | Available | 1 |
| 7 | 55430023000 Vacuum connection | Vacuum connection | 1 | $8.35 | Available | 1 |
| 8 | 55630106000 Cylinder head 300 EXC | Cylinder head 300 EXC | 1 | $195.24 | Out of Stock | Notify Me |
| 9 | 0770078020 O-RING 78,00X2,00 VIT. BLACK | O-RING 78,00X2,00 VIT. BLACK | 1 | $6.15 | Available | 1 |
| 10 | 0770105020 O-ring 105x2 | O-ring 105x2 | 1 | $6.26 | Available | 1 |
| 11 | 58336020090 VACUUM CONNECTION M 6X1 | VACUUM CONNECTION M 6X1 | 1 | $7.80 | Available | 1 |
| 12 | 78015019001 HOSE EPA D=6/10 PER METER | HOSE EPA D=6/10 PER METER | 1 | $73.69 | Available | 1 |
| 13 | 58605083014 Oval head screw M5x14 TX25 | Oval head screw M5x14 TX25 | 6 | $3.99 | Available | 6 |
| 14 | 5483700700015 CONTROL COVER R/S 09 | CONTROL COVER R/S 09 | 1 | $45.20 | Available | 1 |
| 15 | 54837008000 GASKET FOR CONTROL COVER R/S | GASKET FOR CONTROL COVER R/S | 1 | $8.13 | Available | 1 |
| 16 | 5483700500015 CONTROL COVER L/S 09 | CONTROL COVER L/S 09 | 1 | $28.92 | Available | 1 |
| 17 | 54837006000 GASKET FOR CONTROL COVER L/S | GASKET FOR CONTROL COVER L/S | 1 | $8.13 | Available | 1 |
| 18 | 0770116241 O-RING 11,3 X2,4 SILICON | O-RING 11,3 X2,4 SILICON | 4 | $3.99 | Available | 4 |
| 19 | 51005074000 RETAINING PLATE | RETAINING PLATE | 2 | $3.99 | Available | 2 |
| 20 | 54630044000 COLLAR NUT M10 WS=13 | COLLAR NUT M10 WS=13 | 4 | $1.99 | Available | 4 |
| 21 | 0835100351S STUD SCREW DIN0835-M10X35 | STUD SCREW DIN0835-M10X35 | 4 | $2.99 | Out of Stock | Notify Me |
| 22 | 55430030025 CYLINDER BASE GASKET | CYLINDER BASE GASKET | — | $10.55 | Available | 1 |
| 22 | 55430030020 CYLINDER BASE GASKET | CYLINDER BASE GASKET | — | $11.21 | Available | 1 |
| 22 | 55430030040 CYLINDER BASE GASKET | CYLINDER BASE GASKET | — | $10.55 | Available | 1 |
| 22 | 55430030050 CYLINDER BASE GASKET | CYLINDER BASE GASKET | — | $10.33 | Available | 1 |
| 22 | 55430030075 CYLINDER FOOT GASKET | CYLINDER FOOT GASKET | — | $11.65 | Available | 1 |
| 23 | 0402040980 Needle roll.DIN5402 NRB 4X9.8 | Needle roll.DIN5402 NRB 4X9.8 | 2 | $3.99 | Available | 2 |
| 24 | 59007017000 CLAMP YDNAC 10096F (9,6MM) | CLAMP YDNAC 10096F (9,6MM) | 2 | $2.99 | Available | 2 |
| 25 | 61041095075 tube 3,2x9.0 L=75mm | tube 3,2x9.0 L=75mm | 1 | $4.99 | Available | 1 |
| 99 | 55430097000 Gasket set piston 250/300 | Gasket set piston 250/300 | — | $114.50 | Available | 1 |
| 26 | 0770100020 o-ring 10.00x2.00 silicone | o-ring 10.00x2.00 silicone | 1 | $2.99 | Available | 1 |
