CYLINDER, CYLINDER HEAD
Parts (44)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A45030105266 Cylinder cpl. with flange | Cylinder cpl. with flange | 1 | — | Out of Stock | Notify Me |
| 2 | A45030538000 Cylinder + Piston | Cylinder + Piston | 1 | $915.69 | Out of Stock | Notify Me |
| 3 | 0770107020 O-Ring 107x2 | O-Ring 107x2 | 1 | $3.99 | Available | 1 |
| 4 | 0770078020 O-RING 78,00X2,00 VIT. BLACK | O-RING 78,00X2,00 VIT. BLACK | 1 | $6.15 | Available | 1 |
| 5 | T45130060000 Combustion chamber insert EXC | Combustion chamber insert EXC | 1 | — | Available | |
| 6 | A45030006100 Cylinder head | Cylinder head | 1 | $36.29 | Available | 1 |
| 7 | 0603061001 CU-SEAL RING DIN7603-6X10X1 | CU-SEAL RING DIN7603-6X10X1 | 1 | $2.99 | Available | 1 |
| 8 | 0025060106 HH collar screw M6x10 TX30 | HH collar screw M6x10 TX30 | 1 | $3.99 | Available | 1 |
| 9 | 0770023025 O-ring 23x2,5 Viton 75SH | O-ring 23x2,5 Viton 75SH | 1 | $1.99 | Available | 1 |
| 10 | 56530080000 CU-SEAL RING 8 X 16 X 1 | CU-SEAL RING 8 X 16 X 1 | 6 | $2.99 | Available | 6 |
| 11 | 54830079000 COLLAR SCREW M 8X35 WS=13 | COLLAR SCREW M 8X35 WS=13 | 6 | $4.99 | Available | 6 |
| 12 | 55530044000 Collar nut M10-SW13 ZnNi | Collar nut M10-SW13 ZnNi | 4 | $1.99 | Available | 4 |
| 13 | 0835100300 Stud bolt M10x30 | Stud bolt M10x30 | 4 | $2.99 | Available | 4 |
| 14 | A44030035020 Cylinder base gasket | Cylinder base gasket | — | $9.56 | Available | 1 |
| 14 | A44030035025 Cylinder base gasket | Cylinder base gasket | — | $10.22 | Available | 1 |
| 14 | A44030035030 Cylinder base gasket | Cylinder base gasket | — | $8.68 | Available | 1 |
| 14 | A44030035040 Cylinder base gasket | Cylinder base gasket | — | $9.34 | Available | 1 |
| 14 | A44030035050 Cylinder base gasket | Cylinder base gasket | — | $10.00 | Available | 1 |
| 14 | A44030035070 Cylinder base gasket | Cylinder base gasket | — | $11.87 | Available | 1 |
| 14 | A44030035080 Cylinder base gasket | Cylinder base gasket | — | $12.64 | Available | 1 |
| 15 | A44030087000 Engine vent hose | Engine vent hose | 1 | $11.54 | Available | 1 |
| 22 | 0025050256 HH COLLAR SCREW M5X25 ISA30 | HH COLLAR SCREW M5X25 ISA30 | 6 | $1.99 | Available | 6 |
| 23 | T45137007000 Control cover right | Control cover right | 1 | $15.99 | Backorder — Restocking | 1 |
| 24 | A44037006000 Control cover seal, left | Control cover seal, left | 2 | $6.15 | Available | 2 |
| 25 | 0770002226200 X-ring 21.89x2.62 FKM 70 | X-ring 21.89x2.62 FKM 70 | 1 | $2.99 | Available | 1 |
| 26 | A44037005000 exhaust control cover left | exhaust control cover left | 1 | $22.87 | Backorder — Restocking | 1 |
| 28 | 0025060356 HH collar screw M6x35 TX30 | HH collar screw M6x35 TX30 | 5 | $3.99 | Available | 5 |
| 29 | 79435047000 water temperature sensor | water temperature sensor | 1 | $27.93 | Available | 1 |
| 30 | A45041075000 crank case pressure sensor | crank case pressure sensor | 1 | $58.84 | Available | 1 |
| 31 | A44041087000 Pressure sensor flange | Pressure sensor flange | 1 | $14.18 | Available | 1 |
| 32 | 0017060206 SCREW F. PLASTIC K60X20AL SW6 | SCREW F. PLASTIC K60X20AL SW6 | 1 | $3.99 | Available | 1 |
| 33 | 00050210706 VARIABLE ONE-EAR CLAMP 21,0MM | VARIABLE ONE-EAR CLAMP 21,0MM | 1 | $2.99 | Available | 1 |
| 34 | A45041075060 Pressure sensor cover | Pressure sensor cover | 1 | $2.99 | Available | 1 |
| 35 | A45041075050 Pressure sensor EPDM plate | Pressure sensor EPDM plate | 1 | $6.81 | Available | 1 |
| 99 | A44030097000 Sealkit cylinder MX 250/300 | Sealkit cylinder MX 250/300 | — | $112.30 | Available | 1 |
| 16 | 76014060050 EJOMAT DOUBLE PIN 60X12/M6X22 | EJOMAT DOUBLE PIN 60X12/M6X22 | 2 | — | Out of Stock | Notify Me |
| 27 | 51005174000 Retaining cap | Retaining cap | 2 | — | Out of Stock | Notify Me |
| 36 | 0912060353 AH SCREW DIN0912-M 6X35 | AH SCREW DIN0912-M 6X35 | 2 | $2.99 | Available | 2 |
| 18 | T45130505050 Exhaust port insert | Exhaust port insert | 1 | $29.69 | Backorder — Restocking | 1 |
| 17 | 0145810501600S Countersunk screw ISO 14581-M5 | Countersunk screw ISO 14581-M5 | 2 | $0.99 | Backorder — Restocking | 2 |
| 37 | 0377101018000 O-ring 10x1.8 HNBR70 black | O-ring 10x1.8 HNBR70 black | 1 | $1.99 | Available | 1 |
| 38 | A44041023044 Injector | Injector | 1 | $139.14 | Available | 1 |
| 39 | T45141513000 Injector holder | Injector holder | 1 | $61.39 | Backorder — Restocking | 1 |
| 40 | 0025050206S Hex collar screw, M5x20 ISA30 | Hex collar screw, M5x20 ISA30 | 2 | $1.99 | Available | 2 |
