FRAME
Parts (33)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | BT10000CT-CSV-1 Frame red Trial 2019 | Frame red Trial 2019 | 1 | — | Check availability | |
| 2 | BT10000013012 Skid plate racing 2012 | Skid plate racing 2012 | 1 | — | Check availability | |
| 3 | T2606000 Cage nut 6mm | Cage nut 6mm | 8 | — | Check availability | |
| 4 | T0208020 Special screw 8x20 | Special screw 8x20 | 2 | — | Check availability | |
| 5 | T0310140 Screw 10x140 | Screw 10x140 | 1 | — | Check availability | |
| 6 | BT280210069 Nut | Nut | 1 | — | Check availability | |
| 7 | T0301090 Screw 10x90 | Screw 10x90 | 1 | — | Check availability | |
| 8 | T3110003 Nut M10 | Nut M10 | 1 | — | Check availability | |
| 9 | BX250020029 Nut | Nut | 2 | — | Check availability | |
| 10 | BT140003013CT Foot peg set | Foot peg set | 1 | — | Check availability | |
| 11 | T0508050 Buttom head screw 8x50 | Buttom head screw 8x50 | 2 | — | Check availability | |
| 12 | BT27910006 Bushing foot rest | Bushing foot rest | 2 | — | Check availability | |
| 13 | M100004 Spring foot rest left | Spring foot rest left | 1 | — | Check availability | |
| 14 | M100003 Spring foot rest right | Spring foot rest right | 1 | — | Check availability | |
| 15 | T2108001 Nut selflocking 8mm | Nut selflocking 8mm | 2 | — | Check availability | |
| 16 | BT280310883 Special nut | Special nut | 2 | — | Check availability | |
| 17 | T0408016 Screw 8x16 | Screw 8x16 | 2 | — | Check availability | |
| 18 | T0556025 Screw 6x25 | Screw 6x25 | 1 | — | Check availability | |
| 19 | BT280212026 Chain guard | Chain guard | 1 | — | Check availability | |
| 20 | T2206002 Nut selflocking | Nut selflocking | 1 | — | Check availability | |
| 21 | BT280110050 Engine bracket | Engine bracket | 1 | — | Check availability | |
| 22 | T2108002 Nut 8mm DIN 982 | Nut 8mm DIN 982 | 2 | — | Check availability | |
| 23 | BT100503013 O-ring frame | O-ring frame | 1 | — | Check availability | |
| 24 | BT11520CT-CSV-1 Protective cover | Protective cover | 1 | — | Check availability | |
| 27 | T0306020 Screw 6x20 | Screw 6x20 | 1 | — | Check availability | |
| 28 | BT51120GG-CBN-1 Tape | Tape | 1 | — | Check availability | |
| 29 | BT10001CT-CBN-1 Protective cover | Protective cover | 1 | — | Check availability | |
| 30 | BC250014050 Bushing | Bushing | 1 | — | Check availability | |
| 31 | T2206000 Nut 6mm | Nut 6mm | 2 | — | Check availability | |
| 32 | T4008016 Washer 8x16x1,5 | Washer 8x16x1,5 | 2 | — | Check availability | |
| 36 | T0306016 Screw 6x16 | Screw 6x16 | 1 | — | Check availability | |
| 37 | T4006012 Washer 6x12x1,5 | Washer 6x12x1,5 | 1 | — | Check availability | |
| 38 | T4006040 Washer DIN 6798 Zinc | Washer DIN 6798 Zinc | 1 | — | Check availability |
