FRAME
Parts (26)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A53503001000FB Frame A535 | Frame A535 | 1 | $2043.02 | Available | 1 |
| 2 | A53501026000 Steering stop | Steering stop | 1 | $17.26 | Available | 1 |
| 3 | 69008021060 special screw M5x17 | special screw M5x17 | 2 | $3.99 | Available | 2 |
| 4 | 014580060141 Cap head screw ISO 14580 M6x14 | Cap head screw ISO 14580 M6x14 | 1 | $1.99 | Available | 1 |
| 5 | 75001094010 BUSHING MUD FLAP 07 | BUSHING MUD FLAP 07 | 1 | $7.14 | Available | 1 |
| 8 | 0025060306 HH collar screw M6x30 TX30 | HH collar screw M6x30 TX30 | 1 | $3.99 | Available | 1 |
| 9 | A53503053044 Chain slider below, cmpl. | Chain slider below, cmpl. | 1 | $22.59 | Available | 1 |
| 10 | 0047621009000S Screw ISO4762-M10x90 | Screw ISO4762-M10x90 | 1 | $4.99 | Available | 1 |
| 11 | 54630044000 COLLAR NUT M10 WS=13 | COLLAR NUT M10 WS=13 | 1 | $1.99 | Available | 1 |
| 14 | 0035080156S AH-COLLAR SCREW M8X15 TORX45 | AH-COLLAR SCREW M8X15 TORX45 | 4 | $2.99 | Available | 4 |
| 15 | BT280210069 Nut | Nut | 1 | $9.78 | Available | 1 |
| 16 | 0047621014000 Screw ISO4762-M10x140 | Screw ISO4762-M10x140 | 1 | $3.99 | Available | 1 |
| 17 | BT280110050 Engine bracket | Engine bracket | 1 | $57.96 | Available | 1 |
| 18 | 0025080206 HH collar screw M8x20 | HH collar screw M8x20 | 2 | $2.99 | Available | 2 |
| 19 | 0926080003 STOP NUT DIN6926 M8 SS | STOP NUT DIN6926 M8 SS | 2 | $1.99 | Available | 2 |
| 20 | A53503090000 Skid plate | Skid plate | 1 | $378.39 | Available | 1 |
| 21 | 0035080206S SHCS M8x20 TX45 | SHCS M8x20 TX45 | 2 | $6.26 | Available | 2 |
| 22 | 0019080206S FLAT HEAD SCREW M. ISA45 M8X20 | FLAT HEAD SCREW M. ISA45 M8X20 | 1 | $2.99 | Available | 1 |
| 23 | A53503090010 Skid plate rubber | Skid plate rubber | 1 | $26.61 | Available | 1 |
| 24 | A53503090020 Skid plate rubber, rear | Skid plate rubber, rear | 1 | $14.95 | Available | 1 |
| 25 | A53503040010 Footrest kit | Footrest kit | 1 | $160.04 | Available | 1 |
| 26 | A53503041000 Footpeg, front, right | Footpeg, front, right | 1 | $57.30 | Available | 1 |
| 27 | A53503040000 Footpeg, front, left | Footpeg, front, left | 1 | $57.08 | Available | 1 |
| 28 | 0730000201800 Spring clip | Spring clip | 2 | $4.99 | Available | 2 |
| 29 | A53503042000 Footpeg stud | Footpeg stud | 2 | $13.41 | Available | 2 |
| 30 | A53503044000 Footpeg spring | Footpeg spring | 2 | $4.99 | Available | 2 |
